Installation instructions for small spray dryer

The small spray dryer is applicable to the production of micro particle powder in universities, research institutes and laboratories of food, medicine and chemical enterprises. It is widely applicable to all solutions, such as Emulsion and suspension. It is also applicable to the drying of heat sensitive substances, such as biological products, Biopesticide, enzymes, etc.

It can also be used for beverage flavor and pigment, milk and egg products, plant and vegetable extracts, pharmaceutical synthesis, thermosensitive substances, plastic polymers and resin aromatics, blood products, ceramics, superconductors, biochemical products, dyes, soaps, detergents, food Adhesive, oxides, bone powder, tooth powder, etc.

The extensive application also requires us to have a certain understanding of the installation of small spray dryers. Let's take a look at the installation instructions below.

1. Installation of drying chamber. Hold the drying chamber with both hands and insert it diagonally into the fixing clamp of the drying chamber. Tighten the locking nut of the drying chamber (subject to the drying chamber being able to rotate in the clamp).

2. Installation of cyclone separator. Put the lock nut, seal ring and stainless steel gasket of the cyclone separator on the air outlet pipe of the cyclone separator, and then insert them into the air outlet pipe of the equipment together. Adjust the position of the air outlet of the drying chamber and the air inlet of the cyclone separator so that the two openings are straight and aligned. Connect the two openings with clamps, and finally lock the lock nut of the cyclone separator.

3. Connect the aggregate bottle and the cyclone separator with clamps.

4. Connect the aggregate pipe and the drying chamber with clamps.

5. Install the spray chamber onto the equipment, and connect the 4mm air pipe (for needle passing) and 6mm air pipe (for spray).

6. Install the silicone hose onto the Peristaltic pump and insert it into the feed port of the spray chamber.
